SystemAir Danvent DV User Manual


Bilag8—7


8.10Mountsideprofilesandcornersalongtheedgesoftherooftoprotectpersons
ProfilesNandOwiththerectangularholesareforthelongandlowersideoftheroofbecauseraincan
escapethroughtheholes.MounttheprofilestypeNfirstandtheprofileOlastbecausetheprofileOgoes
overtheprofileN.Mountedinthisorder,theprofile
Ocanmatchtheendoftheroofandthesurplus
lengthoftheprofileOwilljustcoverpartofthepreviousprofileN.MounttheprofilesLandMalongthe
longandhigherfrontsideoftheroof.Mountthe4protectioncorners.




8.11Applysealingonplatejointstoensurewaterresistance.
Finishinstallationofthesteelroofbysealingallplatejointswithsiliconetopreventrainwaterfrompassing
intotheunit.Seeexamplesbelowofjointstobesealed.

SystemAir Danvent DV Specifications

General

Brand	SystemAir
Model	Danvent DV
Category	Air Handlers
Language	English
