Additional equipment |
33
230V cont'd
Power supply
Prefuse (A)
Fan fuse (A)
Heater fuse (A)
Total current consumption (A)
Total power consumption (kW)
Total power heater (kW)
Current power consumption fans (A/Unit)
Current consumption heater (A)
Power consumptions fans (kW/Unit)
SR/TR80 HWL, HWH, N 230V
3~230 V+PE, 50Hz 25 C16 18, 5 6,10 6,5 2,4
SR/TR80 EL 5,2 230V
3~230 V+PE, 50Hz 35 C16 B32 29,2 10,70 5,2 6,5 13,1 2,4
SR/TR80 EL 12,3 230V
3~230 V +PE, 50Hz 63 C16 B40 47 17,80 12,3 6,5 30,9 2,4
SR/TR100 HWL, HWH, N 230V
3~230 V+PE, 50Hz 32 C25 23,1 7,90 8,8 3,3
SR/TR100 EL 3,5 230V
3~230 V+PE, 50Hz 50 C25 B32 38,5 14,40 7,1 8,8 17,8 3,3
SR/TR100 EL 10,4 230V
3~230 V+PE, 50Hz 63 C25 B63 60 23,00 15,7 8,8 39,3 3,3
16 Additional equipment
For information concerning additional external equipment such as valve actuators, motorized dampers, roof units, wall
grilles etc. see technical catalogue and their enclosed instructions.
For electrical connections of external components see enclosed wiring chart and separate documentation.
17 Disposal
♦ Ensure material is recycled. Observe national regulations.
♦ The device and the transport packaging are predominantly made from recyclable raw materials.
♦ Disassemble the air handling unit into its components.
♦ Separate the parts according to:
• reusable material
• material groups to be disposed of (metal, plastics, electrical parts, etc.)
