TB9100 Reciter Service Manual Replacing the Network Board 13
© Tait Electronics Limited January 2006
1 Replacing the Network Board
This section describes how to troubleshoot and replace a faulty reciter
network board. Servicing procedures for the reciter digital board and the
reciter RF board are covered in the TB8100 Service Manual.
1.1 Equipment Required
■ Anti-static work environment
■ PC with Ethernet cable.
■ Torque screwdriver (4.5in-lbs) with Torx T-10 bit
■ TB9100 subrack (PA not required)
Figure 1.1 Network Board
DSP LED
flexible
connector
bridge
board
locating
pins
PowerPC LED
Activity LED Tx LED 1PPS coaxial cable
