Technische Alternative UVR 16x2 User Manual

Timer function
143
Parameters
Mode
Available for selection: Pulse, Run-on time, Delay, Minimum
runtime, Blocking time, Astable
Trigger
Slope (only for Pulse
mode)
Retrigger (not shown in
Astable mode)
Available for selection: positive, negative, pos./neg. (see Pulse
mode)
Input Yes, No or, only in pulse mode, Stop (see Retrigger)
Timer runtime
(not visible if defined in the
input variables or in
astable mode)
Enter the timer runtime
ON time
OFF time
(only displayed instead of
timer runtime in astable
mode; not visible if defined
in the input variables)
ON time in Astable mode
OFF time in Astable mode
If enable timer = off
Runtime counter
Available for selection: Zero reset, continues running, Paused
Start timer or Stop timer
Manual starting and stopping of the timer function
(except for Astable mode)
If the timer stops, the runtime counter is set to 0.
➢ If Enable = Off both the timer output and the inverse timer output are switched off.
➢ Action of the runtime counter if enable timer = off:
o "Zero reset" means that the runtime counter will be set to 0 when Enable is
switched OFF. If Enable is switched back ON, the status of the outputs will equate to
counter reading 0 (subject to mode).
o "continues running" means that the runtime counter will continue running when
Enable is switched OFF. If Enable is switched back ON within the timer runtime,
the outputs will be switched according to mode, up to the end of the runtime.
o "Paused" means that the runtime counter is stopped when Enable is switched
OFF. If Enable is switched back ON, the outputs will be switched subject to mode, up
to the end of the runtime.
o "recharge" means that the runtime counter is charged to the set timer runtime
when changing enabling to OFF. If enabling is set back to ON, the timer runs for the
full runtime.
