Calendar
76
Calendar
Function description
The Calendar function makes it possible to operate the heating circuit controller in the operating
modes Party, Holiday, Standby and/or Bank holiday in priority level 3. There are 10 date
windows available for this purpose. Three different set temperatures can be assigned to each
operating mode.
However, it is also possible to issue set values and statuses for other functions as the output in the
specified date windows.
Input variables
Enable
General enabling of the function (digital value ON/OFF)
Holiday derivative time
Analogue value in minutes for bringing the ON time forward for
"Holiday" operating mode
Party derivative time
Analogue value in minutes for bringing the ON time forward for "Party"
operating mode
Bank holiday derivative
time
Analogue value in minutes for bringing the ON time forward for "Bank
holiday" operating mode
Standby derivative time
Analogue value in minutes for bringing the ON time forward for
"Standby" operating mode
➢ With Enable OFF, all statuses will be set to OFF, the operating mode will show Inactive (0)
and the set values for Inactive will be issued
➢ The sources for the derivative times can be other functions (e.g. heating circuit control,
curve function). This allows the use of flexible start and stop times which vary depending on
other parameters (e.g. the outside temperature).
Parameters
Function quantity
Select the function quantity for the set values. A wide range of function
quantities are available, which are applied together with their unit and
their decimal places.
Inactive
Enter the analogue set values for Inactive operating mode and for
Enable = Off.
Party
Enter the analogue set values for Party operating mode.
Holiday
Enter the analogue set values for Holiday operating mode.
Standby
Enter the analogue set values for Standby operating mode.
Bank holiday
Enter the analogue set values and the time window for the Bank
holiday operating mode.
Date window 1 – 10
Access to the sub-menu for each Date window 1 ‒ 10 to set the
parameters
Parameters in Inactive, Party, Holiday or Standby sub-menu
Set value
Set value 1
Enter analogue set value 1
Set value 2
Enter analogue set value 2
Set value 3
Enter analogue set value 3
➢ The set values are available as output variables inside the date window.
