AFG1000 Series Quick Start User Manual
Save/recall instrument setup
You can save setups of the instrument as files in the internal memory or on an
external USB memory device. You can save up to 32 instrument setups in the
instrument internal memory. To save more setups, use a USB memory device.
Setup files saved to a USB memory device are saved with the extension TFS. You
can recall the stored setups from a file in the internal memory or in a USB
memory device.
1.
Push the front-panel Utility
button.
2.
Press Setup.
3.
To save the setup to internal
memory, press Memory to select
Internal.
4.
Use the front panel general
purpose knob to select a file
from Setup0 through Setup31.
Press Save Setup.
NOTE:
The file size is displayed on the
right side. <Empty> indicates the
file is empty.
5.
To recall a setup, select the setup,
press Recall Setup.
6.
To erase a setup file, select it,
press Erase.
