Tektronix AFG1062 Technical Reference

AFG1000 Series Specifications and Performance Verification
5
Specifications
Table 6: Amplitude
Characteristic Description PV ref page
Range
AFG1022 1 mVp-p to 10 Vp-p (into 50 Ω load)
2 mVp-p to 20 Vp-p (into Open circuit or High-Z)
AFG1062 ≤ 25 MHz: 1 mV
p-p
to 10 V
p-p
> 25 MHz: 1 mV
p-p
to 5 V
p-p
(into 50 Ω load)
≤ 25 MHz: 2 mV
p-p
to 20 V
p-p
> 25 MHz: 2 mV
p-p
to 10 V
p-p
(into Open circuit or High-Z)
Accuracy
±(1% of setting +1 m V
p-p
) (at 1 kHz sine waveform), 0 V offset
Resolution 1
mV
p-p
or 4 digits
Units
1
V
p-p
, V
rms,
and Volt (High level and Low level)
Output impedance 50 Ω
1
V
rms
is not available for Pulse, Noise, and Arb waveforms.
(See page 21,
Amplitude test.)
Table 7: DC offset
Characteristic
Description
PV ref page
Range
±
(5 V
pk
– Amplitude V
p-p
/2) into 50 Ω load
±
(10 V
pk
– Amplitude V
p-p
/2)
into Open circuit or High-Z
Accuracy
±(1 % of |setting| + 1 mV + amplitude V
p-p
* 0.5%)
(See page 23,
DC offset test.)
Resolution
1 mV
Output impedance
50 Ω (typical)
Table 8: Counter Specification
Characteristic
Description
PV ref page
Function
Frequency, period, positive Pulse width, Duty cycle
Frequency Range
100 mHz to 200 MHz
Frequency Resolution
6 digits
(See page 24,
Counter test.)
Coupling mode
AC, DC
Voltage Range and Sensitivity, DC coupled (non-modulation signal)
100 mHz to 100 MHz
250 mV
p-p
to 5 V
p-p
(AC+DC)
100 MHz to 200 MHz
450 mV
p-p
to 3 V
p-p
(AC+DC)
Voltage Range and Sensitivity, AC coupled (non-modulation signal)
1 Hz to 100 MHz
250 mV
p-p
to 5 V
p-p
100 MHz to 200 MHz
450 mV
p-p
to 4 V
p-p
Pulse width and Duty cycle
Measure
1 Hz to 10 MHz
Input impedance
1 MΩ with 100 pF parallel
High frequency noise
restraint (HFR)
On / Off (HFR frequency = 500 kHz)
Sensitivity
Low, Middle, High
Trigger level range
± 2.5 V
