Tektronix AFG1062 Technical Reference

AFG1000 Series Specifications and Performance Verification
13
Performance tests
Performance conditions
The tests in this section comprise an extensive, valid confirmation of performance
and functionality when the following requirements are met:
The cabinet covers must be on the Series.
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
The instrument must be operating at an ambient temperature between +0 °C
and +40 °C.
The instrument must have had a warm-up period of at least 30 minutes.
Equipment required
The following table lists the required equipment used to complete the performance
tests.
Table 18: Test equipment
Description Minimum requirements Recommended equipment Purpose
1.
Digital Multi Meter
(DMM)
AC volts, true rms, AC
coupled Accuracy: ±0.1%
to 1 kHz
Agilent 3458A
Measures voltage. Used in
multiple procedures.
DC volts Accuracy: 50 ppm,
resolution 100 μV
Resistance Accuracy: ±0.05 Ω
2.
Power Meter 100 kHz to 250 MHz 1 μW
to 100 mW (-30 dBm to
+20 dBm) Accuracy: 0.02 dB
Resolution: 0.01 dB
R&S NRVS
Measures voltage. Used in
multiple procedures.
3.
Power Head
100 kHz to 250 MHz 1 μW
to 100 mW (-30 dBm to
+20 dBm)
R&S NRV-Z51 Measures voltage. Used
in
multiple procedures.
4.
Frequency Counter
Accuracy: 0.01 ppm Phase
measurement
Agilent 53132A
Checks clock frequency.
5.
Signal Generator
Sine 1 MHz, Pulse 1 MHz
Frequency Accuracy: ± 1 ppm
Tektronix AFG2021
Checks counter
6.
Spectrum Analyzer
20 kHz to 1.25 GHz
Tektronix RSA3303A
Checks output signals.
Harmonics Spurious.
7.
BNC Coaxial Cable
50 Ω, male to male BNC
connector, 91 cm
Tektronix part number
012-0482-00
Signal interconnection
8.
BNC terminator
50 Ω, ±1 Ω, 2 W, DC to
1 GHz, BNC
Tektronix part number
011-0049-02
Signal termination
9.
Attenuator
50 Ω, x10, BNC
Tektronix part number
011-0059-03
Signal attenuation

Tektronix AFG1062 Specifications

General

Model	AFG1062
Manufacturer	Tektronix
Output Channels	2
Output Impedance	50 Ω
Vertical Resolution	14 bits
Category	Function Generator
Waveforms	Sine, Square, Ramp, Pulse, Noise, Arbitrary
Output Amplitude	10 Vpp into 50 Ω
Arbitrary Waveform Length	16 k points
Interface	USB
