Tektronix AFG1062 Technical Reference

Specifications
10
AFG1000 Series Specifications and Performance Verification
General specifications
Table 13: Power
Characteristic Description
Source voltage and frequency 220 - 240 VAC, 100 - 120 VAC, 50/60 Hz, CATⅡ
Power consumption
AFG1022 Less than 28 W
AFG1062 Less than 35 W
Fuse 110 V: 250 V, F1AL
220 V: 250 V, F0.5AL
Table 14: Export control
Characteristic Description
Effective analog bandwidth, typical (Arbitrary waveform at 1 V
p-p
amplitude)
30 MHz
Effective maximum frequency out 10 MHz
Phase noise (At 1 V
p-p
amplitude)
At 20 MHz: < –110 dBc/Hz at 10 kHz offset
Table 15: Environmental
Characteristic Description
Temperature range
Operating 0 °C to 40 °C
Non operating -20 °C to 60 °C
Humidity
Operating ≤ 80%, non-condensing
Altitude
Operating Up to 3,000 meters ( apx. 9843 feet)
Non operating Up to 12,000 meters (apx. 39,370 feet)
Cooling Method Fan cooling
Table 16: System characteristics
Characteristic Description
Warm-up time, typical 30 minutes minimum
Communication Interface USB host (front panel) and device (rear panel)
Net weight 3.4 kg (7.5 lbs), approximate
Dimensions (overall)
Height
111.16 mm (4.38 in)
Width 229.16 mm (9.02 in)
Depth 306.36 mm (12.06 in), including rear boot
