Tektronix AFG3000 Series Technical Reference

Specifications
Table 8 : DC offset (cont.)
Characteristic Description
PV reference
page
Output impedance 50 Ω
1
AFG3011/3011C:Add1.0mVper°Cforoperationoutsidetherangeof20°Cto30°C.
AFG3021B / 3021C / 3022B / 3022C and AFG3101 / 31010C / 3102 / 3102C: Add 0.5 mV per °C for operation outside the range of 20 °C to 30 °C.
AFG3251 / 32
51C / 3252 / 3252C: Add 2.0 mV per °C for operation outside the range of 20 °C to 30 °C.
Table 9: Internal noise add
Characteristic Description
Range
0% to 50% of amplitude setting
Resolution
1%
Table 10
: Output characteristics
Characteristic Description
PV reference
page
Sine wave
Flatness (at 1.0 V
p-p
amplitude (+4 dBm), relative to 1 kHz)
(See page 54,
AC Fla
tness
test.)
AFG3011 / 3011C
<5MH
z: ±0.15 dB
5MHz≤ frq ≤ 10 MHz: ±0.3 dB
AFG3021B / 3021C /
3022B / 3022C
<5MH
z: ±0.15 dB
5MHz≤ frq < 20 MH z: ±0.3 dB
20 MHz ≤ frq ≤ 25 MHz: ±0.5 dB
AFG3051C / 3052C
<5MHz: ±0.15dB
5MHz≤ frq < 45 MH z: ±0.3 dB
45M
Hz ≤ frq ≤ 50 MHz: ±0.5 dB
AF
G3101 / 3101C / 3102
/ 3102C
<5MHz: ±0.15dB
5M
Hz ≤ frq < 25 MHz: ±0.3 dB
25 MHz ≤ frq ≤ 100 MHz: ±0.5 dB
AFG3251 / 3251C / 3252
/ 3252C
<5
MHz: ±0.15 dB
5MHz≤ frq < 25 MH z: ±0.3 dB
25 MHz ≤ frq < 100 MHz: ±0.5 dB
1
00 MHz ≤ frq < 200 MHz: ±1.0 dB
200 MHz ≤ frq ≤ 240 MHz: ±2.0 dB
Harmonic distortion (at 1.0 V
p-p
amplitude)
(See page 56,
Harmonics
Distortion test.)
AFG3011 / 3011C 10 Hz ≤ frq < 20 kHz: < –60 dBc
20 kHz ≤ frq < 1 MHz: < –55 dBc
1MHz≤ frq ≤ 10 MHz: < –45 dBc
10 AFG3000 Series Specifications and Performance Verification
