Specifications
Table 16: Syste
m characteristics
Characteristic Description
Warm-up time,
typical
20 minutes min
imum
Power on self
diagnostics, typical
<10s
Configurati
on times, typical
USB
LAN
GPIB
Function change 81 ms 81 ms 81 ms
Frequency change (except
Pulse)
2.5 ms 6 ms 3.2 ms
Frequency
change (Pulse)
40 ms 37 ms 32 ms
Amplitude change 90 ms 97 ms 90 ms
Select user Arbitrary
wavefor
m is 4K points
(USB memory)
48 ms 50 ms 49 ms
Select user Arbitrary
waveform is 128K points
(USB m e
mory)
260 ms 266 ms 240 ms
Data download, typical
4000 po
ints A rb waveform data (8 Kbytes)
GPIB: 320 ms
USB: 47 ms
LAN: 7
8ms
Acoustic noise, typical < 50 dBA
Weight (approximate) 4.5 kg (9.92 lbs)
Dimensions
Refer to the following illustrations.
18 AFG3000 Series Specifications and Performance Verification
