Tektronix AFG3000 Series Technical Reference

Specifications
Table 10: Output characteristics (cont.)
Characteristic Description
PV reference
page
AFG3011 / 3011C /
3021B / 3021C / 3022B /
3022C
4ns
AFG3051C / 3052C /
3101 / 3101C / 3102 /
3102C
1nsat1GS/s
4 ns at 250 MS/s
AFG3251 / 3251C / 3252
/ 3252C
500 ps at 2 GS/s
4 ns at 250 MS/s
1
Exclude harmonics and channel crosstalk.
Table 11: Modulation
Characteristic Description
AM (Amplitude Modulation)
Carrier waveforms Standard waveforms (except P ulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, N oise, and Arb
1
Internal modulating frequency
2 mHz to 50.00 kHz
Depth
0.0% to 120.0%
FM (Frequency Modulation)
Carrier waveforms Standard waveforms (except P ulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, N oise, and Arb
2
Internal modulating frequency
2 mHz to 50.00 kHz
Peak deviation
AFG3011 / 3011C DC to 5 MHz
AFG3021B / 3021C /
3022B / 3022C
DC to 12.5 MHz
AFG3051C / 3052C DC to 25 MHz
AFG3101 / 3101C / 3102
/ 3102C
DC to 50 MHz
AFG3251 / 3251C / 3252
/ 3252C
DC to 120 MHz
PM (Phase Modulation)
Carrier waveforms Standard waveforms (except P ulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, N oise, and Arb
2
14 AFG3000 Series Specifications and Performance Verification
