Tektronix AFG3000 Series Technical Reference

Performance verification
Equipment required
The following t
able lists the required equipment used to complete the performance
tests.
Table 19: Test equipment
Description Minimum requirements Recommended equipment Purpose
1. Digital Mult
i Meter
(DMM)
AC volts, true rm s, AC
coupled Accuracy: ±0.1% to
1kHz
DC volts Accuracy: 50 ppm,
resolution 100 μV
Resistanc
e Accuracy: ±
0.05 Ω
Agilent 3458
A
Measures vol
tage. Used in
multiple procedures.
2. Power Mete
r
100 kHz to 2
50 MHz 1 μW
to 100 mW (-30 dBm to
+20 dBm) Accuracy: 0.02 dB
Resoluti
on: 0.01 dB
R&S NRVS
Measures v
oltage. Used in
multiple procedures.
3. Power Head 100 kHz to 250 MHz 1 μW
to 100 mW (
-30 dBm to
+20 dBm)
R&S NRV-Z
5
Measures voltage. Used in
multiple
procedures.
4. Frequency Counter
Accurac
y: 0.01 ppm Phase
measurement
Agilent
53132A
Checks clock frequency.
5. Oscilloscope 1 GHz Bandwidth 50 Ω input
termination
Tektronix TDS5104B Checks output signals. Used
in multiple procedures.
6. Spectrum Analyzer 20 kHz to 1.25 GHz Tektronix RSA3303A Checks output signals.
Harmo
nics Spurious.
7. BNC Co
axial Cable
50 Ω,m
ale to male BNC
connector, 91 cm
Tektronix part number
012-0
482-00
Signa
l interconnection
8. BNC terminator 50 Ω,±1Ω ,2W,DCto
1GHz,BNC
Tekt
ronix part number
011-0049-02
Signal termination
9. Attenuator
50 Ω , x10, BNC
Tektronix part number
011-0059-03
Signal attenuation
10. Adapter Dual-Banana
Plug
BNC (female) to dual banana
Tektronix part number
103-0090-00
Signal interconnection to a
DMM
11. Adapter
BN
C(female)-N(male)
BN
C (female) to N (male)
Tektronix part number
10
3-0045-00
Si
gnal interconnection to a
Spectrum Analyzer
T
est record
Photocopy the test records and use them to record t he performance test results for
your AFG3000 Series Arbitrary Function Generators.
AFG3000 Series Specifications and Performance Verification 27
