Tektronix DPO2000 Series Programmer's Manual

Command Groups
Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:THReshold:REF<x>
Sets or returns the trigger search setup and
hold lower threshold to determine where
to place a mark. Ref<x> is the reference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:HOLDTime
Sets or returns the hold time setting for an
setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:SETTime
Sets or returns the setup time setting for an
setup/hold search
SEARCH:SEARCH<x>:TRIGger:A{:
TRANsition|:RISEFall}:DELTatime
Sets or returns the transition time setting for
an transition search
SEARCH:SEARCH<x>:TRIGger:A{:
TRANsition|:RISEFall}:POLarity
Sets or returns the polarity setting for an
transition search
SEARCH:SEARCH<x>:TRIGger:A{:
TRANsition|:RISEFall}:SOUrce
Sets or returns the source setting for an
transition search
SEARCH:SEARCH<x>:TRIGger:A{:
TRANsition|:RISEFall}:WHEn
Sets or returns the condition setting for an
transition search
SEARCH:SEARCH<x>:TRIGger:A:TYPe Sets or returns the trigger type setting for a
search
SEARCH:SEARCH<x>:TRIGger:A:
UPPerthreshold:CH<x>
Sets or returns the waveform upper threshold
level for all channel waveform searches
SEARCH:SEARCH<x>:TRIGger:A:
UPPerthreshold:MATH
Sets or returns the waveform upper threshold
level for all math waveform searches
SEARCH:SEARCH<x>:TRIGger:A:
UPPerthreshold:REF<x>
Sets or returns the waveform upper threshold
level for all reference waveform searches
Status and Error Command Group
Use the commands in the Status and Error Command Group to determine the
status of the oscilloscope and control events.
Several commands and queries used with the oscilloscope are common to all
IEEE488.2 compliant devices. The IEEE Std 488.2-1987 defines these commands
and q ueries. The c
ommon commands begin with an asterisk (*) character.
Table 2-30: Status and Error Commands
Command
Description
ALLEv?
Returns all events and their m essages
BUSY?
Returns oscilloscope status
*CLS Clears status
DESE Sets or returns the bits in the Device Event
Status Enable Register
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-37
