Tektronix DPO5000 Series User Manual

Install your ins
trument
Operating requirements
MSO/DPO70000DX, MSO/DPO70000C, and DPO7000C
1. Place the instrument on a cart or bench.
The instrument should rest on its bottom
or rear feet. An optional rack mounting
kit is available. Observe the following
clearance requirements and dimensions:
DPO7000C Models: MSO/DPO70000C/DX Models:
Top:
0in(0mm) 0in(0mm)
Left and right side: 0 in (0 mm) on right side
3 in (76 mm) on left side
3in(76mm)
Bottom:
0 in (0 mm) standing on feet, flip
stands d
own
0 in (0 mm) standing on feet, flip
stands d
own
Rear:
0in(0m
m) on rear feet
0in(0m
m) on rear feet
2. Width:
17.96 i
nches (456 mm)
17.75 i
nches (451 mm)
3. Height:
10.9 i
nches (277 mm)
11.48
inches (292 mm)
4. Befo
re operating the instrument, verify
the ambient temperature:
5°Ct
o+45°C(+41°Fto+113°F)
5°Ct
o+45°C(+41°Fto+113°F)
5. Verify the operating humidity: 8% to 80% relative humidity with
a maximum wet-bulb temperature
of +
29 °C (+84 °F) at or below
+45 °C (+113 °F), noncondensing
Upper limit derated to 30% relative
hum
idity at + 45 °C (+113 °F)
8% to 80% relative humidity at up
to+32°C(+90°F)
5% t
o 45% relative humidity above
+32 °C (+90 °F) up to +45 °C
(+113 °F), noncondensing, and
is l
imited by a maximum wet-bulb
temperature of +29.4 °C (+85 °F)
(derates relative humidity to 32%
at
+45 °C (+113 °F))
6. Ve
rify the operating altitude:
DP
O7000C models: 3,000 m
(9,843 feet)
MS
O/DPO70000C/DX m odels:
3,000 m (9,843 feet), derate
maximum operating temperature
b
y 1 °C per 300 meters
(984.25 feet) above 1500 meters
(4921.25 feet) altitude.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 3
