Getting Acquain

ted with Your Instrument

DSA70000B and, DPO70000B

1. Removable hard disk drive

2. PS-2 connector for mouse

3. USB host ports

4. Centronics Parallel Port

5. RJ-45 LAN connector to c onnect to

network

6. Video port to

connect a monitor

7. TekLink con

nector

8. GPIB port to

connect to controller

NOTE. Some instruments may have

additional audio connectors.

9. Line In connector

10. Line Out connector for speaker

11. Mic connector for microphone

12. Video port to connect a monitor

13. COM 1 serial port

14. P S-2 connector for keyboard

15. CTR Bass speaker

16. S ide speaker out

17. Rear speaker out

18. A uxiliary output

19. Reference output

20. E xternal reference input

DSA70000B a

nd DPO700 00B Series

18 MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual
