Command Groups
Table 2-20: Configuration Commands (cont.)
Command
Description
CONFIGuration:ANALOg:GNDCPLG?
This query returns a boolean value to indicate whether the
instrument supports the ground coupling feature for analog
channels. As this feature is not supported on MSO/DPO4000B
or MDO4000/B/C models, this query always returns 0.
CONFIGuration:ANALOg:MAXBANDWidth? Returns the maximum bandwidth for analog channels.
CONFIGuration:ANALOg:MAXSAMPLERate? This query returns the maximum sample rate for analog channels.
CONFIGuration:ANALOg:NUMCHANnels? This query returns the number of analog channels.
CONFIGuration:ANALOg:RECLENS? This query returns a list of supported record lengths for analog
channels.
CONFIGuration:ANALOg:VERTINVert?
This query returns a boolean value to indicate whether the
instrument supports the vertical invert feature for analog
channels.
CONFIGuration:APPLications:CUSTOMMask? Indicates w hether the Custom Mask test feature is present and
enabled.
CONFIGuration:APPLications:LIMITMask?
This query returns a boolean value to indicate whether the
instrument supports the mask/limit test application feature.
CONFIGuration:APPLications:POWer?
This query returns a boolean value to indicate whether the
optional power application feature is present.
CONFIGuration:APPLications:STANDARDMask? Indicates whether the Standard Mask test feature is present
and enabled.
CONFIGuration:APPLications:VIDPIC? Indicates whether the Video Picture feature is present and
enabled.
CONFIGuration:ARB? Indicates whether or not the arbitrary function generator
hardware is present, and the user-defined arbitrary waveform
generation feature is enabled. Note that this is different than the
CONFIGuration:AFG? query.
CONFIGuration:AUXIN?
This query returns a boolean value to indicate whether the
instrument has an A ux Input connector.
CONFIGuration:BUSWAVEFORMS:ARINC429A?
This query returns a boolean value to indicate whether the
optional ARINC429 bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:AUDIO?
This query returns a boolean value to indicate whether the
optional audio bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:CAN?
This query returns a boolean value to indicate whether the
optional CAN bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:CANFD?
This query returns a boolean value to indicate whether the
optional CAN FD bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:ETHERNET?
This query returns a boolean value to indicate whether the
optional Ethernet triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:FLEXRAY?
This query returns a boolean value to indicate whether the
optional FlexRay bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:I2C?
This query returns a boolean value to indicate whether the
optional I
2
C bus triggering and analysis feature is present.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-21
