Commands Listed in Alphabetical Order
Examples
RF:FREQuency 3
.0E+06
sets the center frequency to 3 MHz.
RF:FREQuency? might return 3.0E+06, indicating that the center frequency
has been set to
3MHz.
RF:LABel
This command specifies (or queries) a label for the RF frequency domain
waveform.
Conditions
MDO3000, MDO4000/B, or MDO4000C models with option SA3 or SA6 only.
Group
RF
Syntax
RF:LABel <QString>
RF:LABel?
Related Commands
RF:RF_AMPlitude:LABel, RF:RF_FREQuency:LABel, RF:RF_PHASe:LABel
Arguments
<QString>isaquotedstringofupto32characters.
RF:MEASUre:ACPR:ADJACENTPAIRs
When the RF measurement type has been set to ACPR, the frequency domain
displays a Main channel in the center (Ch:Main), and a side channel group on
either side of the Main Channel. There can be either 1, 2 or 3 channels within
each side group; this command specifies that number. (Lower Area 1, 2 and 3
would be on the left side of the Main channel; Upper Area 1, 2 and 3 would be
on the right side).
To set the measurement type to ACPR, use the command
RFMEASUre:TYPe
ACPR
.
The Adjacent Channel Power Ratio (ACPR) is the ratio of channel power between
two user-selected channels (a side channel and a main channel).
NOTE. The oscilloscope will maintain the span to fit all the channels on-screen,
plus a margin of 10% (5% on either side.)
Conditions
MDO3000, MDO4000/B, or MDO4000C models with option SA3 or SA6 only.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-551
