Tektronix MDO4000B Series User Manual

Command Groups
Zoom Command G
roup
Use the commands in the Zoom Command Group to expand and position the
waveform display horizontally, without changing the time base settings.
Table 2-49:
Zoom Commands
Command
Descriptio
n
ZOOm? Returns the horizontal positioning and scaling of the zoom display
ZOOm{:MODe|:STATE} This command specifies the zoom mode
ZOOm:ZOOM<x>? Returns the current horizontal positioning and scaling of the zoom display
ZOOm:ZOOM<x >:FACtor? Returns the zoom factor of the zoom window. <x> can only be 1
ZOOm:ZOOM<x >:P OSition This command specifies the horizontal position of the zoom window in terms of 0 to 100% of
the overview window. <x> can only be 1
ZOOm:ZOOM<x >:SCAle This command specifies the horizontal zoom scale of the zoom window. <x> can only be 1
ZOOm:ZOO M<x >:S TATE Specifies or returns a trace as zoomed, on or off. <x> can only be 1
ZOOm:ZOOM<x>:TRIGPOS? This query returns the time relative to trigger of the center of the zoom box, for the currently
selec
ted waveform.
2-110 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
