Phaser 740 and 750 Color Printers
Cork separator pad
The cork separator pad should be replaced whenever the multi-purpose pick roller is
replaced. The life is about 30k prints.
1.
Grasp the paper guide and push in and down to the bottom of it travel, then
tilt it forward.
2.
With a small, narrow, flat-blade screwdriver, reach behind the cork
separator pad and free the two retaining hooks hold the separator pad in
place. Note the spring is under tension. Remove the separator pad and
spring.
3.
Install a new cork separator pad.
Removing the cork separator pad
Spring
Paper guide
Cork separator pad
740-7-6
Retaining
hooks
Paper guide
