Tektronix TBS1052B User Manual

Environmental
Temperature
Operating 0 to +50 ºC
Nonoperating –40 to +71 ºC
Humidity
Operating and nonoperating Up to 85% RH at or below +40 ºC
Up to 45% RH up to +50 ºC
Altitude
Operating and nonoperating Up to 3,000 m (9,843 ft.)
Regulatory
Electromagnetic compatibility Meets Directive 2004/108/EC, EN 61326-2-1 Class A; Australian EMC Framework
Safety UL61010-1:2004, CSA22.2 No. 61010-1:2004, EN61010-1:2001, IEC61010-1:2001
Specifications
122 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual

Tektronix TBS1052B Specifications

General

Bandwidth	50 MHz
Channels	2
Sample Rate	1 GS/s
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Interfaces	USB 2.0
Record Length	2.5 kpts
Display	7-inch WVGA (800 x 480)
Trigger Types	Edge, Pulse Width
Display Type	Color LCD
Display Resolution	800 x 480
Input Impedance	1 MΩ
Power Supply	100 to 240 V
