Nominal Traits
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
2–15
Table 2–5: Nominal traits — Triggering system (cont.)
Name Description
Communication Trigger Modes of
Operation
(Option 2C Comm Trigger, Not available on
TDS 600C and TDS 714L)
Standard Name Code
1
Bit Rate
OC1/STM0 NRZ 51.84 Mb/s
OC3/STM1 NRZ 155.52 Mb/s
OC12/STM4 NRZ 622.08 Mb/s
DS0 Sgl Masks
2
64 kb/s
DS0 Dbl Masks
2
64 kb/s
DS0 Data Contra Masks
2
64 kb/s
DS0 Timing Masks
2
64 kb/s
E1 AMI 2.048 Mb/s
E2 AMI 8.44 Mb/s
E3 AMI 34.368 Mb/s
E4 CMI 139.26 Mb/s
E5 (CEPT) NRZ 565 Mb/s
STM1E CMI 155.52 Mb/s
DS1 AMI 1.544 Mb/s
DS1A AMI 2.048 Mb/s
DS1C AMI 3.152 Mb/s
DS2 AMI 6.312 Mb/s
DS3/DS3 Rate AMI 44.736 Mb/s
DS4NA CMI 139.26 Mb/s
STS-1 AMI 51.84 Mb/s
STS-3 CMI 155.52 Mb/s
FC133 NRZ 132.8 Mb/s
FC266 NRZ 265.6 Mb/s
FC531 NRZ 531.2 Mb/s
FC1063 NRZ 1.0625 Mb/s
D2 NRZ 143.18 Mb/s
D1 NRZ 270 Mb/s
FDDI NRZ 125 Mb/s
4:2:2 SMPTE 259M-D NRZ 360 Mb/s
10 Base-T NRZ 10 Mb/s
100 Base-T NRZ 125 Mb/s
Gigabit Ethernet NRZ 1.25 Gb/s
1
AMI = Alternate Mark Inversion. CMI = Code Mark Inversion. NRZ = Non-return to Zero.
2
These Telecom DS0 standards are automatically selected from the Mask Menu. The trigger uses Pulse/Width trigger.
Table 2–6: Nominal traits — Display system
Name Description
Video Display 7 inch diagonal, with a display area of 5.04 inches horizontally by 3.78 inches vertically
TDS 520D, 540D, 580D, and 680C: Monochrome display
TDS 654C, 684C, 694C, 714L, 724D, 754D, 784D, and 794D: Color display
Video Display Resolution 640 pixels horizontally by 480 pixels vertically
