Page #149 background image
TDS2CMA Communications Module
130
TDS1000/2000-Series Digital Oscilloscope User Manual
Checking Module Installation
To check that t he module is correctly installed, power on the
oscilloscope. The power-on screen should list the TDS2CMA module
and include the message Power-up Tests Passed. If the oscilloscope
does not recognize the module a t power on, follow the steps in
Troubleshooting Module Installation.
Troubleshooting Module Installation
If the oscilloscope does not recognize the module at power on,
follow these steps:
1. Power off the oscilloscope.
2. Follow the ESD precautions on page 128.
3. Disconnect all cables from the module.
4. Remove the module as described on page 129.
5. Examine the oscilloscope connec tor for bent, broken, or missing
pins. If any pins are bent, carefully straighten them.
6. Reinstall the m odule onto the oscilloscope.
7. Power on the oscilloscope. If the oscilloscope still does not show
the module installed, c ontact the nearest Tektronix service c enter.
