Tenda A9 User Manual

15
Web UI Features
Change the Extender’s WiFi Settings
Here you can see the base station WiFi
name, connection status, and connection
time.
Select a WiFi name below to start to
extend a WiFi network again. (You can
refer to steps in Extend the WiFi
Network Using a Smartphone for
details.)
By default, the WiFi name and password
of the extender are changed to the same
as that of the WiFi router (the base
station). If you want to customize them,
please do as follows.
① Click on the upper right corner and
click .

Tenda A9 Specifications

General

Type	Network transmitter & receiver
Ethernet LAN data rates	- Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Antenna gain level (max)	3 dBi
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA-PSK, WPA-TKIP, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Product color	Grey, White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	47.7 mm
Width	56 mm
Height	111 mm
