Tenda AC10 User Manual

100
11.4.2 Enable Tenda techical support to access the web UI
Scenario: You encounter a problem in configuring the router, and the router can access the
internet.
Goal: Ask the Tenda technical support to help you configure the router remotely.
Solution: You can configure the remote management function to reach the goal.
Assume that:
− The IP address of Tenda technical support: 210.76.200.101
− The WAN port IP address of the router: 202.105.106.55
Configuring procedures:
Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in
to the web UI of the router.
Step 2 Choose Administration > Remote Web-based Management.
Step 3 Tick Enable of Remote Web-based Management function.
Step 4 Set Management IP Address to Specific, and enter the IP address of Tenda technical
support, which is 210.76.200.101 in this example.
Step 5 Enter a port number used to access the router remotely.
Step 6 Click OK at the bottom of the page.
---End
When the configurations are completed, the Tenda technical support can access and manage the
router by visiting “http://202.105.106.55:8888” on the computer.
WAN IP address:
202.105.106.55
Tenda technical support
IP address: 210.76.200.101
Access with an IP
address

Tenda AC10 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Transmit power	23 dBmW
Antennas quantity	4
Antenna gain level (max)	5 dBi
VPN support	PPTP Client, PPTP Server, L2TP Client
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	3
Cables included	LAN (RJ-45)
Package type	Box
Package weight	810 g
Number of products included	1 pc(s)
Firewall security	Forbid UDP Flood Attack, Forbid TCP Flood Attack, Forbid ICMP Flood Attack, Forbid WAN Ping from Internet, PPTP Pass Through, L2TP Pass Through, IPSec Pass Through
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, IC
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	390 mm
Width	198 mm
Height	70 mm
Weight	350 g
