Tenda AC8 User Manual

96
Step 3 Click the drop-down box of Clone MAC Address, and choose Clone Local Host MAC to
copy the MAC address of the management device, or Manual to enter the desired MAC
address.
Step 4 Click OK on the bottom of the page.
---End
11.2.4 Change the WAN Speed
To access the configuration page, log in to the web UI of the router, and choose Administration >
WAN Parameters.
When the Ethernet cable is not damaged and connected to the WAN port properly, but Ethernet
cable disconnected is still shown on the Internet Settings page, you can try to change the WAN
Speed to 10 Mbps full duplex or 10 Mbps half duplex to solve the problem. Otherwise, keep the
default settings.
MTU parameter description
MTU
Application
1000 Mbps auto-
negotiation
It indicates that the speed and duplex mode are determined through the negotiation
with the peer port.
10 Mbps FDX
10 Mbps Full Duplex. It indicates that the WAN port is working at the speed of 10
Mbps, and the port can receive and send data packets at the same time.

Tenda AC8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Antenna gain level (max)	6 dBi
Output current	1 A
Output voltage	9 V
AC input voltage	200 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Firewall security	Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, CCC, SRRC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127 mm
Width	200 mm
Height	33.6 mm
