Tenda AC8 User Manual

90
10.2 IPv6 LAN setup
To access the page, log in to the web UI of the router and choose IPv6 > IPv6 LAN Settings.
You can change the IPv6 LAN settings here.
Parameter description
Parameter
Description
IPv6 LAN
Address
It specifies two types of IPv6 LAN address assignment.
⚫
Auto: The router generates the IPv6 address according to its LAN IPv6 address. By default,
the prefix has 64 digits.
⚫
Manual: You need to set the IPv6 LAN address manually.
IPv6 LAN
Prefix
Length
It specifies two types IPv6 LAN prefix address assignment.
⚫
Auto: The router obtains an LAN prefix from the upstream device.
⚫
Manual: You need to set the IPv6 LAN prefix manually.
DHCPv6
DHCPv6 (Dynamic Host Configuration Protocol for IPv6) is used to assign IP addresses and
prefix to IPv6 hosts on a network. It is the IPv6 equivalent of the DHCP for IPv4. This is also
known as a stateful autoconfiguration.
DHCPv6
Address
Assignment
Method
It specifies the assignment type of DHCPv6 address for the clients connected to the router.
⚫
Auto: DHCPv6 stateless configuration. Clients obtain their IPv6 address through Router
Advertisement (Stateless Auto Address Configuration) and other parameters are allocated
by the DHCPv6 server.
⚫
Manual: DHCPv6 stateful configuration. The DHCPv6 server automatically assigns IPv6
addresses/prefixes and other network configuration parameters (e.g. DNS server
addresses, etc.) to clients. The user needs to manually configure the start ID and the end ID.

Tenda AC8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Antenna gain level (max)	6 dBi
Output current	1 A
Output voltage	9 V
AC input voltage	200 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Firewall security	Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, CCC, SRRC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127 mm
Width	200 mm
Height	33.6 mm
