TK 61650-18-OP-EN
23
Figure 6. Condenser
Evaporator
The evaporator is mounted on the ceiling inside the cargo box. The cover
can easily be removed for service.
Figure 7. Evaporator
Electronic Control System
The Electronic Control System is composed of an Electronic Control Module
(located inside the condenser unit), an interface Board Module, and the HMI.
This HMI allows the truck driver to operate the Thermo King refrigeration
unit.
Figure 8. HMI
Description
The Electronic Control System has the following characteristics:
• Auto Start
• Soft Start
UUnniitt DDeessccrriippttiioonn
