Specifications
Refrigeration System
Contact your Thermo King dealer for refrigeration system service or
maintenance.
Compressor
Displacement (cc) 47.7
Number of cylinders
6
Electrical Control System
Fuses
12 Vdc 24 Vdc
Fuse 1: Main Fuse 100 amps 60 amps
Fuse 3: Evaporator Fan Motor (EFM1) 15 amps 10 amps
Fuse 5: Signals 20 amps 10 amps
Fuse 6: Drain Heaters (H3 and H4) 2 amps 2 amps
Fuse 7: Transformer AC Power Supply 2
10 amps 10 amps
Fuse 14: Vehicle Ignition Switch 5 amps 5 amps
Fuse 20: Transformer AC Power Supply (located at
compressor motor contactor in condenser section)
4 amps 4 amps
Fuse 25: Battery Fuse 5 amps 5 amps
Fuse 30: Condenser Fan Motor (CFM) (located in
CF1 wire near terminal strip in condenser section)
16 amps 10 amps
Fuse 31: Fuse - Heater 1 20 amps 20 amps
Fuse 32: Fuse - Heater 2 20 amps 20 amps
Fuse 33: Fuse - Heater 3 20 amps 20 amps
Fuse 34: Fuse - Heater 4 20 amps 20 amps
