OPERATING MANUAL DAF290 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
Traction sheave with integrally cast brake disc
360 mm rim diameter / 480 mm brake disc diameter
8 mm rope diameter
Number of grooves in version
a) double wrap = 14 semicircular grooves, unhardened
b) single wrap = 5 - 9 seat or vee grooves with hardened groove flanks
The groove form (wedge angle with vee grooves, or undercut angle of the
seat grooves) must be selected according to the required driving force.
Weight:
Machine weight incl. traction sheave 750 kp
Machine weight incl. frame and rope pulley 1050 kp
Technical data of double-vane magnet:
Power supply
Holding current: (at U
= 90V) 1.3 A
Pick-up current (at U
= 50V) 2.4 A
Rated retentive voltage: 100 V
for field forcing device: 180 V
Type of protection: IP65
With the DAF 290, both coils are connected in series.
Technical data of forced ventilation:
Operating voltage: 400 - 460 V
Mains frequency: 50 / 60 Hz
Nominal power: 0.27 kW
Current: 0.42 A
Air volume: 600 m³/h
Noise level: 68 dB(A)
3.2 Machine base frame - optional -
The machine base frame is manufactured and delivered depending on the
order. See corresponding order drawings. The machine base frames are
intended for installation in the machine room above the shaft.
The rope run-in and departure on the traction sheave and rope pulley must
be fitted with protective covers. The cover on the traction sheave must be
secured by a switch. The drive shuts down automatically if the rope guard on
the traction sheave is removed while work is being carried out on the
machine.
