ENGINE DISASSEMBLY
2.5 TEMPERATURE SENSOR REMOvAL
Unscrew the sensor (1) and remove it from the head.
Check that the OR gasket (2) is not damaged.
2.6 HEAD REMOvAL
Remove the spark plug and the temperature sensor as described in the
Undo the screws (1).
Remove the head (2).
