31
16
15
18
19
21
5
19
ENGINE DISASSEMBLY
Put graphite grease around the pin (20) and on the screw (19) without dirt-
ying the thread.
Insert the spring (17) in the pin (18) and on the screw (19).
Reassemble the roller bearing (16) and the seal (15) with the printed side
facing out.
Smear the socket (14) with graphite grease and reassemble it in the cylin-
der.
