42
1
2
8
9
A
C
B
ENGINE DISASSEMBLY
2.16 WATER PUMP
2.16.1
It is possible to replace the water pump seal without removing the trans-
mission card.
Unscrew the screws (1) on the pump cover (3); the screw
-
minum washer (2).
Remove the cap (A) from the generator cover (B).
Unscrew the impeller (8) of the pump.
Remove the seal (9) with a screwdriver and replace it.
