ENGINE DISASSEMBLY
2.12 CLUTCH
2.12.1
Unscrew the screw (1) and remove the actuator (2).
2.12.2
Remove the piston (3).
Re-mount everything, proceeding in the opposite order to disassembly.
GEAR SENSOR
Unscrew the two grub screws (1).
Remove the sensor (2).
