33
12
5
6
22
26
25
ENGINE DISASSEMBLY
Insert the lever (5) into the pin (12).
Allen key (22) on the screw (6) and screw the nut (4).
With the valve completely closed, the distance between the upper surface
must be 56 mm; for the adjustment loosen the nut (25) and act on the
