19
LED STATUS INDICATIONS DURING STARTUP
- Initialization in Progress
Flashes red, green and blue (2 times per second)
- The Aircraft is in "Bind"Mode
Flashes yellow very rapidly (3 times per second)
- The Aircraft is Not Connected/Linked to the Transmitter
Flashes blue rapidly (5 times per second)
- The Aircraft is in a No-Fly Zone *
Flashes red and white rapidly (5 times per second)
Please see the instruction manual for more
information regarding no-fly zones
LED STATUS INDICATIONS BEFORE/DURING FLIGHT
- The Aircraft is in Smart Mode without GPS lock
Flashes red and white (red for one second,white for
another second and then circulate)
- The Aircraft is in Angle Mode with GPS lock
Glows solid purple
- The Aircraft is in Angle Mode without GPS lock
Flashes red and white (red for one second,white
for another second and then circulate)
- The Aircraft is in Home Mode
Flashes red rapidly (2 times per second)
- First Level low Voltage Battery Warning
Flashes red,green and blue every 3 seconds
- Second Level low Voltage Battery Warning
Flashes red,green and blue continuously
- GPS Disabled
Flashes purple(1 flash per second)
- Compass Calibration Required
Flashes yellow twice between any LED indication
LED STATUS INDICATIONS FOR CALIBRATION MODES
- Compass Calibration Mode Entered
Flashes red and green slowly
- Compass Calibration Started
Flashes red,green and rapidly(3 times per second)
- Accelerometer Calibration Mode Entered
Flashes red,green and blue slowly
- Accelerometer Calibration Mode Started
Flashes red, green, and blue rapidly.
LED STATUS INDICATION
- The Aircraft is in Smart Mode with GPS lock
Glows solid green
