Servicing the Air Cleaner (continued)
G424731
4. Pull the latch outward, rotate the air-cleaner
cover counterclockwise, and remove the cover.
5. Before removing the filter, use low-pressure air
—275 kPa (40 psi), clean and dry—to help
remove large accumulations of debris packed
between outside of primary filter and the air-
cleaner housing.
IMPORTANT
Avoid using high-pressure air, which could force dirt through the filter into the intake
tract.
G424732
6. Remove the primary filter from the air-
cleaner housing
.
Note: Do not clean the primary filter.
Maintenance: Engine Maintenance Page 6–18 3466-702 A
