Backlapping the Cutting Units (continued)
2. Wash all lapping compound off of the cutting units.
3. Adjust the cutting unit reel-to-bedknife as needed.
4. Rotate the backlap levers to the F (mow) position.
G425519
Backlap lever (front cutting units 4, 1, and 5)
Backlap lever (rear cutting units 2 and 3)
Forward rotation (mow)
5. For a better cutting edge, run a file across the front face of the bedknife after lapping.
Note: This removes any burrs or rough edges that may have built up on the cutting
edge.
6. Close and latch the hood.
Chassis Maintenance
Inspecting the Seat Belt
1. Inspect the seat belt for wear, cuts, and other damage. Replace the seat belt(s) if any
component does not operate properly.
2. Clean the seat belt as necessary.
Maintenance: Chassis Maintenance Page 6–52 3466-702 A
