MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewthemanualbeforeoperatingthemachine.
Engineowner'smanual1
Usethemanualtoreferenceengineinformation.
DeclarationofConformity
1
Noiseratingcerticate
1
ForCEcompliance
Ignitionkeys2
Starttheengine.
1
InstallingtheRollBar
Partsneededforthisprocedure:
1Rollbar
4
Bolt(1/2x3-3/4inches)
4
Flangenut(1/2inch)
Procedure
1.Removethetopcratesupportfromthecrate.
2.Removetherollbarfromthecrate.
3.Removethe3boltsthatsecuretherightside
covertothemachineandremovethesidecover.
4.Removethe2boltsthatsecurethefuse-block
brackettotheROPSbracketasshowninFigure
3.
g233711
Figure3
1.Rollbar
4.Bolt(1/2x3-3/4inches)
2.Rightsidecover
5.RightROPSbracket
3.Fuseblockbracket
6.Flangenut(1/2inch)
5.Alignthefuse-blockbracketontherightROPS
bracketanduse4bolts(1/2x3-3/4inches)and
4angenuts(1/2inch)toinstalltherollbarinto
theROPSbracketsoneachsideofthemachine.
6.Torquethefastenersto136to149N∙m(100to
110ft-lb).
7.Usethe3boltsthatyoupreviouslyremovedto
securetherightsidecovertothemachine.
11
