WARNING
Incorrectbatterycableroutingcoulddamage
thetractorandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
Ifcorrosionoccursattheterminals,disconnectthe
cables,negative(-)cablerst,andscrapetheclamps
andterminalsseparately.Connectthecables,positive
(+)cablerst,andcoattheterminalswithpetroleum
jelly.
LocatingtheFuses
Thefusesintheelectricalsystemarelocatedunder
theseat(Figure38).
g195277
Figure38
1.Diagnosticlights,and
glow—7.5A
5.Lightsandleak
detector—15A
2.Reelengage,lift/lower,
fan—7.5A
6.System—10A
3.Liftreel,E-reelenable,
andovertemp—7.5A
7.Ignitionswitchand
start/run—10A
4.Nofuse8.ECMlogicandpower—2
A
ThefusesfortheE-reelwireharnessarelocated
undertherightside-cover,belowtheconsole(Figure
39).
g028670
Figure39
1.Fuses—35A
41
