Figure3
1.Fender
3.Securerearofeachtaillightbrackettorearof
framebracketswitha5/16x1in.bolt,.344”I.D.
atwasherandlocknut,asshowninFigure3.
Figure4
1.Fender
2.Supportplate
4.Looselysecureafendertoeachsideofframewith
asupportplate,(5)3/8x1–1/4in.bolts,anda
locknutasshowninFigure4.
Note:Weldnutsareinplacetosecure(4)ofthe
bolts.
5.Tightenallfasteners.
2
InstalltheWheels
Partsneededforthisprocedure:
10Wheelnut
2Frontwheel
10Wheelnut
2Rearwheel
Procedure
1.Removelugnutssecuringwheelstowheelbrackets.
Retainlugnuts.
2.Mountwheelsandinstalllugnuts.Torquelugnuts
to45–65ft-lb.
Figure5
1.Wheel2.Wheelnut
14
