Figure71
1.Clutchpedal
2.3.75”±.12”
Note:Forceisappliedsotheclutchreleasebearing
lightlycontactspressureplatengers.
4.Tightenthejamnutsaftertheadjustmenthasbeen
attained.
5.Recheckthe3.75”+.12”dimensionafterthe
jamnutshavebeentightenedtoensureproper
adjustment.Readjust,ifnecessary.
6.Reconnectthereturnspringtotheclutchlever.
Important:Makesuretherodendispositioned
squarelyontheball,nottwisted,andremains
paralleltotheclutchpedalafterthejamnutis
tightened(Figure72).
Figure72
1.Clutchcablerodend
3.Rodendjamnut
2.Clutchpedal
4.Parallel
Note:Theclutchfreeplayshouldneverbeless
than.75”.
7.Rechecktheclutchsafetyswitchadjustment
(Figure73).Theenginemustnotcrankunlessclutch
pedalis1.25”±.12”fromoor.Ifanadjustmentis
required,loosenswitchjamnutsandadjustupor
down.
Figure73
1.Clutchswitch
AdjustingParkingBrake
ServiceInterval:Every200hours
1.Removerubbergripfromparkingbrakelever
(Figure74)
Figure74
1.Parkingbrakelever
2.Grip
2.Loosensetscrewsecuringknobtoparkingbrake
lever(Figure75).
3.Rotateknobuntilaforceof30–40lbs.isrequired
toactuatelever.
52
