Thefullbedweighsapproximately325pounds,
sodonottrytoinstallorremoveitbyyourself.
Useanoverheadhoistorgetthehelpoftwoor
threeotherpeople.
Figure13
1.Spacerbracket3.Carriagebolt
2.Wearblock
1.Assureliftcylindersarefullyretracted.
2.Carefullysetbedontovehicleframealigningrearbed
pivotplateholeswithholesinrearframechannel
andinstall(2)clevispinsandlynchpins(Figure12).
3.Withbedlowered,secureeachcylinderrodend,to
appropriateslotsinbedmountingplateswithclevis
pinandlynchpin.Insertclevispinfromoutsideof
bedwithlynchpintowardoutside(Figure12).Rear
slotsareforfullbedinstallationandfrontslotsare
for2/3bedinstallation.
Note:Enginemayneedtobestartedtoextend
orretractcylindersforalignmentwithholes.Keep
ngersout!
Note:Unusedslotcanbepluggedwithaboltand
nuttopreventassemblyerrors.
4.Startengineandengagehydraulicliftlevertoraise
bed.Releaseliftleverandturnoffengine.Installthe
bedsafetysupporttopreventaccidentalloweringof
thebed.RefertoUsingBedSafetySupport.
5.Installlynchpinstoinsideendsofclevispins.
Note:Ifautomatictailgatereleasehasbeen
installedonbed,makesurefrontdumplinkrodhas
beenplacedoninsideofleftsideclevispinbefore
lynchpinisinstalled.
ProductOverview
Controls
Note:Determinetheleftandrightsideofthemachine
fromthenormaloperatingposition.
AcceleratorPedal
Theacceleratorpedal(Figure14)givestheoperatorthe
abilitytovaryengineandgroundspeedofthevehicle,
whenthetransmissionisingear.Depressingthepedal
increasesengineRPMandgroundspeed.Releasing
pedalwilldecreaseengineRPMandgroundspeedof
themachine.
Figure14
1.Acceleratorpedal3.Brakepedal
2.Clutchpedal
ClutchPedal
Theclutchpedal(Figure14)mustbefullydepressed
todisengageclutchwhenstartingengineorshifting
transmissiongears.Releasepedalsmoothlywhen
transmissionisingeartopreventunnecessarywearon
transmissionandotherrelatedparts.
Important:Donotrideclutchpedalduring
operation.Clutchpedalmustbefullyoutorclutch
willslipcausingheatandwear.Neverholdthe
vehiclestoppedonahillusingtheclutchpedal.
Damagetotheclutchmayoccur.
BrakePedal
Thebrakepedal(Figure14)isusedtoapplyservice
brakestostoporslowvehicle.
19
