InstalltheSteeringWheel
Partsneededforthisprocedure:
1
Steeringwheel
1
Cap
1Washer
1Foamseal
Procedure
1.Removethejamnutfromthesteeringshaft.Slide
thefoamseal,steeringwheelandwasheronto
steeringshaft(Figure6).
2.Securesteeringwheeltoshaftwithjamnutand
tightenitto10-15ft-lb.
3.Installcaptosteeringwheel.
Figure6
1.Steeringwheel3.Cap
2.Jamnut4.Washer
4
InstalltheFrontFenders
Partsneededforthisprocedure:
2
Frontfender
10
Sockethexheadbolt,#10x3/4”in.
20Washer,.210I.D.
10
Locknut,#10
Procedure
1.Alignthevefendermountingholeswiththeholes
ineachsideofbody(Figure7).
2.Mountafendertoeachsideofbodywith(5)#10x
3/4in.socketheadbolts,(10)atwashersand(5)
#10locknuts.Positionawashernexttobolthead
andlocknut.
Figure7
1.Fender
15
