TABLE OF CONTENTS
Page Page
SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . 3 - 4
SAFETY AND INSTRUCTION DECALS. . . . . . 4
LOOSE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . 6
SET UP INSTRUCTIONS
Install Tongue . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assemble Hopper . . . . . . . . . . . . . . . . . . . . . 7
BEFORE OPERATING
Check Hydraulic System . . . . . . . . . . . . . . . . . 8
Check Tire Pressure . . . . . . . . . . . . . . . . . . . . . 8
Attach Topdresser To Towing Vehicle. . . . . . 8
CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . 9
LUBRICATION. . . . . . . . . . . . . . . . . . . . . . . . . . 10
MAINTENANCE
Bleeding Hydraulics . . . . . . . . . . . . . . . . . . . . . 11
Changing Oil Filter. . . . . . . . . . . . . . . . . . . . . . 11
Oil Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wheel Motor Nut Torque . . . . . . . . . . . . . . . . . 11
Brush To Conveyor Belt Adjustment . . . . . . . 12
Chain Tension . . . . . . . . . . . . . . . . . . . . . . . . 12
Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Conveyor Belt Installation/Tension . . . . . . . . . 13
ELECTRIC SCHEMATIC . . . . . . . . . . . . . . . . 14
HYDRAULIC SCHEMATIC . . . . . . . . . . . . . . . 15
TROUBLE SHOOTING . . . . . . . . . . . . . . . 16 - 17
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
IDENTIFICATION AND ORDERING . . . . . . . . . 18
MAINTENANCE CHART . . . . . . . . . . . . . . . . . . 19
WARRANTY. . . . . . . . . . . . . . . . . . . . Back Cover
SAFETY INSTRUCTIONS
BEFORE OPERATING
1. Read and understand all operating and safety
instructions. Before operating this unit, become
familiar with all controls and know how to stop
quickly. A replacement manual is available by
sending complete Model and Serial Number to:
The Toro Company
8111 Lyndale Avenue South
Minneapolis, MN 55420
2. Before each use, be sure all bolts and nuts
are tight.
3. Do not modify this equipment in any manner.
4. When guards are removed for service, replace
them before operating machine. Guards are for
your protection.
WHILE OPERATING
5. NEVER open the hydraulic oil cap until ALL air
pressure has been released.
6. The weight of the topdresser when filled with
sand is approximately 3500 lbs. The towing
vehicle should have adequate brakes to handle
this weight. Check the specifications in the towing
vehicle’s operator manual pertaining to towing
weight.
7. NEVER carry passengers on the machine, and
keep everyone away from the areas of operation.
8. NEVER allow children to operate the machine.
Do not allow adults to operate the machine without
proper instructions.
9. Make sure all hydraulic fittings are tight and all
hydraulic hoses are in good condition before
operating this unit.
10. Keep hands and feet out of hopper when unit
is operating or engine is running on towing vehicle.
11. To avoid loss of control, NEVER, tow the unit
faster than 12MPH.
3
The safety alert symbol means
CAUTION, WARNING or DANGER -
"personal safety instruction". Read
and understand the instruction
because it has to do with safety. Failure to
comply with the instruction may result in
personal injury.
To Next Page
