AdjustingtheAnti-scalp
Rollers
42-inchMowerDecksOnly
Wheneveryouchangetheheightofcut,adjusttheheight
oftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssotherollersdonottouch
thegroundinnormal,atmowingareas.
1.Disengagetheblade-controlswitch(PTO)andengage
theparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Adjusttheanti-scalprollersto1ofthefollowing
positions:
•Upperhole—usethispositionwiththemowerdeck
inthe63mm(2-1/2inch)andbelowheight-of-cut
positions(Figure18).
•Lowerhole—usethispositionwiththemower
deckinthe76mm(3inch)andaboveheight-of-cut
positions(Figure18).
g019929
1
2
3
4
5
Figure18
1.Anti-scalproller4.Upperhole—themower
deckinthe63mm
(2-1/2inch)andbelow
height-of-cutpositions
2.Lowerhole—themower
deckinthe76mm(3inch)
andaboveheight-of-cut
positions
5.Bolt
3.Flangenut
AdjustingtheAnti-scalp
Rollers
54-inchMowerDecksOnly
Wheneveryouchangetheheightofcut,adjusttheheight
oftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssotherollersdonottouch
thegroundinnormal,atmowingareas.
1.Disengagetheblade-controlswitch(PTO)andengage
theparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Adjusttheanti-scalprollers(Figure19)tomatchthe
closestheight-of-cutposition.
G010233
1
2
3
4
Figure19
1.Anti-scalproller3.Flangenut
2.Bolt4.Holespacing
PushingtheMachinebyHand
Important:Alwayspushthemachinebyhand.Donot
towthemachine,becausedamagemayoccur.
Thismachinehasanelectric-brakemechanism.Topushthe
machine,theignitionkeyneedstobeintheRUNposition.
Thebatteryneedstobechargedandfunctioningforthe
electricbraketobedisengaged.
PushingtheMachine
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Settheparkingbrake,shutofftheengine,andwaitfor
allmovingpartstostopbeforeleavingtheoperating
position.
3.Locatethebypassleversontheframeonbothsidesof
theengine.
4.Movethebypassleversforwardthroughthekeyhole
anddowntolocktheminplace(Figure20).
23
