ServicingtheFuses

Theelectricalsystemisprotectedbyfuses.Itrequiresno

maintenance;however,ifafuseblows,checkthecomponent

orcircuitforamalfunctionorshort.

Fusetype:

•Main—F1-30A,blade-type

•ChargeCircuit—F2-25A,blade-type

1.Removethescrewssecuringthecontrolpaneltothe

machine.

Note:Retainallfasteners.

2.Liftthecontrolpaneuptoaccessthemainwiring

harnessandfuseblock(Figure40).

3.Toreplaceafuse,pulloutthefusetoremoveit(Figure

40).

G014921

Figure40

1.Main—30A

2.Chargecircuit—25A

4.Returnthecontrolpaneltoitsoriginalposition.

Note:Usethescrewsremovedpreviouslytosecure

thepaneltothemachine.

DriveSystem

Maintenance

CheckingtheTirePressure

ServiceInterval:Every25hours—Checkthetirepressure.

Maintaintheairpressureinthefrontandreartiresas

specied.Uneventirepressurecancauseunevencut.Check

thepressureatthevalvestem(Figure41).Checkthetires

whentheyarecoldtogetthemostaccuratepressurereading.

Refertothemaximumpressuresuggestedbythetire

manufactureronthesidewallofthecasterwheeltires.

Inatethereardrivewheeltiresto90kPa(13psi).

Figure41

1.Valvestem
