Premaintenance
Procedures
RaisingtheSeat
Engagetheparkingbrakeandlifttheseatforward.
Youcanaccessthefollowingcomponentsbyraisingtheseat:
•Serialplate
•Servicedecal
•Seat-adjustmentbolts
•Fuellter
•Batteryandbatterycables
RaisingtheFrontofthe
Machine
Ifyouneedtoraisethefrontofthemachine,usethevery
frontedgeasshowninFigure24.
Important:Topreventdamagetothesteering
mechanism,ensurethattheveryfrontedgeofthe
machineisusedforjackingpoints.
Figure24
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greaseallthelubrication
points.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurface,anddisengagethe
blade-controlswitch.
2.Engagetheparkingbrake,shutofftheengine,remove
thekey,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Cleanthegreasettingswitharag(Figure25and
Figure26).
Note:Makesuretoscrapeanypaintoffthefrontof
thetting(s).
Figure25
1.Frontcastertire
Figure26
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance.
3.Greaseevery25operating
hours.
2.Checkthetirepressure
every25operatinghours.
4.Engine
4.Connectagreaseguntoeachtting(Figure25and
Figure26).
5.Pumpgreaseintothettingsuntilgreasebeginsto
oozeoutofthebearings.
