Slope
Indicator
G01
1841
Figure
3
This
page
may
be
copied
for
personal
use.
1.
The
maximum
slope
you
can
safely
operate
the
machine
on
is
15
degrees
.
Use
the
slope
chart
to
determine
the
degree
of
slope
of
hills
before
operating.
Do
not
operate
this
machine
on
a
slope
greater
than
15
degrees.
Fold
along
the
appropriate
line
to
match
the
recommended
slope.
2.
Align
this
edge
with
a
vertical
surface,
a
tree,
building,
fence
pole,
etc.
3.
Example
of
how
to
compare
slope
with
folded
edge
7
6
8
