Figure59
1.Cover2.Screw
5.Usingaspringremovaltool,(ToroPartNo.92-5771),
removetheidlerspringfromthedeckhooktoremove
tensionontheidlerpulleyandrollthebeltoffthe
pulleys(Figure60andFigure61).
WARNING
Thespringisundertensionwheninstalled
andcancausepersonalinjury.
Becarefulwhenremovingthebelt.
g017639
1
2
3
3
5
4
6
7
7
Figure60
MowerDeckswith2Blades
1.Idlerpulley5.Enginepulley
2.Mowerbelt
6.Spring-removaltool
3.Outsidepulley
7.Mower-deckhandles
4.Spring
G014931
1
2
3
3
4
5
6
Figure61
MowerDeckswith3Blades
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Spring-removaltool
6.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure60andFigure61).
7.Usingaspringremovaltool,(ToroPartNo.92-5771),
installtheidlerspringoverthedeckhookandplacing
tensionontheidlerpulleyandmowerbelt(Figure60
andFigure61).
8.Installthepulleycovers(Figure59).
InstallingtheMower
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Engagetheparkingbrake,shutofftheengine,remove
thekey,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowestposition.
5.Lifttherearofthemowerdeckandguidethehanger
bracketsovertherearliftrod(Figure58).
6.Attachthefrontsupportrodtothemowerdeckwith
theclevispinandhairpincotter(Figure57).
7.Installthemowerbeltontotheenginepulley;referto
ReplacingtheMower-DeckBelt(page43).
44
